Type/Shape |
6-String T5 Thinline |
| Back & Sides |
Sapele |
| Top |
Maple |
| Neck |
Sapele with Gloss Finish |
| Fretboard |
Ebony |
| Fretboard Inlay |
Serj Tankian Energy Wheel |
| Headstock Overlay |
Serj Tankian Energy Wheel |
| Binding |
Black |
| Bridge |
Ebony |
| Nut & Saddle |
Bone |
| Tuning Machines |
Chrome-plated Taylor Tuners |
| Strings |
Medium Gauge (.011-.049) Electric Nanoweb® Coated Elixir® Strings (light-gauge acoustic optional) |
| Hardware |
Taylor Chrome-plated |
| Scale Length |
24 7/8 Inches |
| Truss Rod |
Adjustable |
| Neck Width at Nut |
1 11/16 Inches |
| Number of Frets |
21 |
| Fretboard Radius |
15 Inches |
| Bracing |
T5 Custom Bracing |
| Finish |
Gloss |
| Color Options |
Black (Opaque) |
| Cutaway |
Venetian |
| Pickups |
Three magnetic pickups: an under-fretboard neck humbucker, a visible bridge humbucker, and an acoustic body sensor mounted to the inside surface of the top. |
| Pickup Switching |
5-Way
Position 1. Under-fretboard humbucker + body sensor in series (acoustic)
Position 2. Under-fretboard humbucker (dark & round)
Position 3. Bridge humbucker (twang to crunch)
Position 4. Bridge humbucker + under-fretboard humbucker in parallel (50’s hollowbody)
Position 5. Bridge humbucker + under-fretboard humbucker in series (thick, bright & full) |
| Left-Handed |
Available; No Charge |
| Body Width |
16 Inches |
| Body Depth |
2.35 Inches |
| Body |
20 Inches |
| Overall Length |
40 3/4 Inches |
| Case |
Taylor T5 Hardshell (black) |
| Unique Features |
Black with maple top, red purfling, unbound f-holes, certificate of authenticity. |
| Price |
$3198.00 U.S. Suggested Retail |
| Notice |
Prices, specifications, and availability are for the North American market only and are subject to change without notice. |
